The XD Series batch fryers are the basic frying equipment of Xindong Machinery, utilizing oil-water mixture technology with automatic temperature control and automatic slag scraping. They are suitable for small to medium scale production, laboratory R&D, and as auxiliary units in large production lines. The heating source is electricity, and the whole machine is made of stainless steel specially used for food machinery.
Product Description
Oil-water mixture technology: During frying, residues automatically sink into the water without carbonizing, and can be discharged through the drain valve. The oil in the residues is separated and returned to the oil layer, achieving significant oil saving.
Precise temperature control: Temperature range 0‑300℃, heating temperature adjustable 0‑230℃, accuracy ±1℃. Independent temperature control for the water layer with natural air cooling and forced water circulation ensures the lower water temperature remains ≤80℃.
Easy operation: Automatic feeding, discharging and stirring save labor. Equipped with observation glass tube and oil drain valve detection device for accurate water level monitoring.
Stainless steel construction: High‑quality 304 stainless steel, durable and compliant with food hygiene standards.
Technical Parameters Table
| Model | External Dim. (mm) | Frying Tank Dim. (mm) | Power (kW) | Oil Capacity (kg) | Applicable Products |
|---|---|---|---|---|---|
| XD-300 | 380×600×900 | 300×440×280 | 4.5 | 20 | Prepared foods, fish, pasta, meat, nuts |
| XD-400 | 480×640×900 | 400×440×280 | 6 | 28 | Same as above |
| XD-500 | 580×640×900 | 500×440×280 | 6/9 | 35 | Same as above |
| XD-600 | 680×640×900 | 600×440×280 | 12 | 40 | Same as above |
| XD-650 | 730×640×840 | 650×440×280 | 12 | 45 | Same as above |
| XD-800 | 880×640×900 | 800×440×280 | 15 | 55 | Same as above |
| XD-850 | 930×640×900 | 850×440×280 | 15/18 | 58 | Same as above |
| XD-1000 | 1080×650×950 | 1000×450×300 | 18/24 | 70 | Same as above |
| XD-1200 | 1280×650×950 | 1200×550×260 | 24/36 | 88 | Same as above |
Frequently Asked Questions
This machine is designed for processing a wide range of food raw materials. Depending on the specific model, it can handle fresh, chilled, or frozen materials within a defined size and moisture range. For optimal performance, we recommend confirming the raw material specifications before ordering.
The equipment is designed to handle potatoes of varying sizes. For certain processes such as cutting or peeling, adjustable settings or size grading solutions can be provided to ensure consistent output quality.
We provide customized solutions based on your factory layout, processing capacity, and production requirements. Our engineering team can assist with line design and technical planning.
Our solution service typically includes process analysis, equipment configuration, line layout drawings, operation guidance, and technical support. Upon request, we can also assist with installation guidance, commissioning, and operator training through online support.
We provide long-term after-sales support for complete processing lines, including technical consultation, troubleshooting assistance, spare parts supply, and system upgrade advice. Detailed operation manuals and maintenance guidelines are provided to ensure smooth daily operation.
