TCA’s “Frying Trio” is specially designed for small granular materials such as rice grains. It integrates a tilting fryer, a de‑oiling machine, and a vacuum cooling line into one continuous production system. All units work seamlessly: materials first enter the XDF-1500×1500 tilting fryer (gas heating, automatic tilting discharge), then go to the XDS-720 de‑oiling machine for rapid oil removal, and finally pass through the FY-3000 vacuum cooling line for negative‑pressure air cooling, which quickly brings down the temperature and preserves crispness. The whole line can be customized with stainless steel thickness, touch screen interface, emergency stop positions, and company logo, meeting safety and hygiene standards for Thailand and Southeast Asian markets. It delivers efficient, stable, and clean frying production.
Process Flow
Product Advantages
The XDF-1500×1500 tilting fryer is heated by LPG gas and specially designed for small granular materials such as rice grains. It features automatic tilting discharge, and the frying basket mesh size can be customized for efficient oil draining. The body is made of 2mm thick 304 stainless steel. The electrical control box is equipped with a touch screen, and multiple emergency stop switches are provided for safe operation.
Gas heating with reserved burner interface (burner purchased locally)
Frying basket mesh customized for no leakage and efficient draining; basket thickness 1.5mm stainless steel
Outer shell thickness 2mm stainless steel; control box thickness 1.5mm stainless steel
Touch screen mounted at 1.35‑1.4m height; flat‑type buttons
Discharge motor with braking function, short pause time during basket tilting
Exhaust pipe covered with stainless steel protective guard to prevent burns
Bottom wiring protected by stainless steel tubes, heat‑resistant
One emergency stop on control box and three on the fryer body
Customer logo can be printed on the machine and on the touch screen interface
| Parameter | Value / Description |
|---|---|
| Model | XDF-1500×1500 |
| Equipment Name | Tilting Fryer |
| Heating method | LPG gas (burner purchased locally) |
| Voltage / Frequency | 380V / 50Hz three‑phase |
| Dimensions (approx.) | 1500×1500×H mm |
| Basket material | 304 stainless steel, thickness 1.5mm |
| Body material | 304 stainless steel, thickness 2mm |
| Control box material | 304 stainless steel, thickness 1.5mm |
| Controller | Touch screen |
| Applicable products | Rice grains, small particle foods |
The XDS-720 de‑oiling machine (centrifugal de‑oiler) is used for rapid oil removal from fried materials. During feeding, it rotates slowly to evenly distribute the product inside the basket. After de‑oiling, material can be discharged in batches to prevent accumulation. Working together with the fryer, it significantly reduces the oil content of the final product.
| Parameter | Value / Description |
|---|---|
| Model | XDS-720 |
| Equipment Name | De‑oiling Machine (Centrifugal De‑oiler) |
| Voltage / Frequency | 380V / 50Hz three‑phase |
| Material | 304 stainless steel |
| Function | De‑oiling after frying |
| Discharge | Batch type |
Vacuum Cooling Line
The FY-3000 vacuum cooling line uses negative pressure air cooling technology to rapidly cool down high‑temperature products after de‑oiling, preventing moisture regain and maintaining crispness. The line is 3 meters long with an outlet height of 1.3 meters. It features cleaning doors and a 60‑mesh filter before the fans for easy maintenance and hygiene.
| Parameter | Value / Description |
|---|---|
| Model | FY-3000 |
| Equipment Name | Vacuum Cooling Line |
| Dimensions | 3000×W×H mm (width & height customizable) |
| Voltage / Frequency | 380V / 50Hz three‑phase |
| Material | 304 stainless steel |
| Cooling method | Negative pressure air cooling |
| Outlet height | 1.3m |
| Cleaning door size | 400×600mm |
| Filter | 60‑mesh stainless steel screen |
Frequently Asked Questions
This machine is designed for processing a wide range of food raw materials. Depending on the specific model, it can handle fresh, chilled, or frozen materials within a defined size and moisture range. For optimal performance, we recommend confirming the raw material specifications before ordering.
The equipment is designed to handle potatoes of varying sizes. For certain processes such as cutting or peeling, adjustable settings or size grading solutions can be provided to ensure consistent output quality.
We provide customized solutions based on your factory layout, processing capacity, and production requirements. Our engineering team can assist with line design and technical planning.
Our solution service typically includes process analysis, equipment configuration, line layout drawings, operation guidance, and technical support. Upon request, we can also assist with installation guidance, commissioning, and operator training through online support.
We provide long-term after-sales support for complete processing lines, including technical consultation, troubleshooting assistance, spare parts supply, and system upgrade advice. Detailed operation manuals and maintenance guidelines are provided to ensure smooth daily operation.
